eMMC 4.5 Card Slave Controller
Key Features
- Compatible with eMMC/MMC specification 4.5.
- Supports Dual Data Rate (DDR) data transfer.
- Enhanced MMC features including Boot, Sleep Mode, Reliable Write, Multiple Partitions and Security.
- Supports e2.MMC command set and HS200 mode for 200MByte/sec data rate.
- Simple 32-bit bus master interface to DMA data into user memory space.
- Optional interrupt-based transfer mode to allow local CPU maximum control.
- Optional two clock domain implementation allows user bus interface and MMC clock operates at different clock domains.
- Selectable maximum block size from 512 to 16Kbytes.
- Process most commands automatically without needing support from user logic.
- Supports eMMC/MMC 4.5 command set and standard slave register set.
- Choice of user interface bus including AHB, AXI, APB, PLB, Wishbone, SH4 and Avalon bus.
Technical Specifications
Availability
Now
