AGIC Tape Out First Silicon at 14nm FinFET Technology

AGIC C-Fuse OTP has been taped out on the foundry’s 14nm technology platform on June 20^th. In addition, AGIC will have a bunch of tape out events from 180nm to 22nm platform in Tier 1 foundries later 2019.

July 4^th, 2019 — AGI Corporation (AGIC), a leading-edged non-volatile memory (NVM) IP provider, today announced the first tape-out of its C-Fuse OTP on 14-nanometer FinFET process technology.

Comparing to 28/22nm process technology, 14nm FinFET technology offers 50~55% higher speeds and consumes 50~60% less power at the same speed. The features of superior performance and the advantage of power consumption make 14nm FinFET a must-to-port process for automotive electronic, next generation high-end mobile computing and to benefit the using of IoT sensors for real-time monitoring.

As IC reliability and security have become extremely important, the existing one-time programmable memory solutions shall add more supplements to reduce the serious side effects, such as data retention in floating gate OTP or high defect rate occurred in anti-fuse OTP. C-Fuse logic-compatible OTP is given birth through the fundamental theories and delivers the industry’s smallest footprint and lowest power Logic NVM IP solution.

C-Fuse technology, based on AGIC Particle Momentum, enables a wide range of applications for its “power-efficient” and “high temperature tolerated.” To accommodate the rapidly shifting IoT market, C-Fuse is tailored for automotive, AIoT era, and edge computing solutions especially in advance nodes.

In collaboration with one of the most advanced pure play wafer foundries, AGIC C-Fuse OTP has been taped out on the foundry’s 14nm technology platform on June 20^th. In addition, AGIC will have a bunch of tape out events from 180nm to 22nm platform in Tier 1 foundries later 2019.

Welcome to visit our office and have more detail discussion if you are interested to know more detail about AGIC technology

About AGIC Technology:

1. Smaller area to lower the cost for silicon wafer.
2. No charge pump (CP) required.
3. Field programmability during system development.
4. Density supports a widely range from 8K to 4M bits.
5. Low voltage/current PGM and read.
6. High-Temp Immunity (>650°C~1000°C) and high reliability from -55°C to 175°C.
7. Supporting BCD/BJT/DRAM/Flash/CDMOS/MS and HV processes for analog, power and LCD/OLED/Touch Panel applications.
8. Portable across all Nodes, from 350nm to 5nm and beyond.
9. Require very lower power consumption.
10. High security and difficult-to-reverse engineer.

Artificial General Intelligence Cosmos IP total solution

Welcome to visit our website www.agicip.com and contact with us Sales@agicip.com for more detail presentation and discussion.
