Fully custom Digital Radio Link based on either our FSK or PSK modulation schemes. Data is split into packets or frames and modulated for transmission over cable (e.g. coax/twisted pair) or wireless. Achieves typical data rates of up to 10 Mbps. Small implementation size ideal for FPGA.
Note that this is a custom design. Please contact Zipcores with your exact requirements and we would be happy to provide a solution for you.
Packet-based Digital Radio Link
Overview
Key Features
- Fully custom solution
- Separate Modulator/Demodulator pair
- FSK or PSK modulation schemes
- Small implementation size
- Compatible with a wide range of DACs/ADCs
- Typical data rates of up to 10 Mbps
Benefits
- Technology independent soft IP Core
- Suitable for FPGA, SoC and ASIC
- Supplied as human-readable source code
- One-time license fee with unlimited use
- Field tested and market proven
- Any custom modification on request
Block Diagram
Applications
- Software defined radio
- Medium to long-range telemetry
- SRD and ISM band devices
- Low cost RF applications
- Transmission of digital video/audio
Deliverables
- VHDL source-code (or Verilog on request)
- Simulation test bench
- Examples and scripts
- Full pdf datasheet
- One-to-one technical support
- One years warranty and maintenance
Technical Specifications
Foundry, Node
All
