PowerPC Bus Slave

Key Features

• Fully supports PowerPC 60x bus protocol including PowerPC 603, 604, 740, 750 and MPC8260.
• Designed for ASIC or PLD implementations in various system environ-ments.
• Fully static design with edge triggered flip-flops.
• Direct support for standard asynchronous SRAM and synchronous BURST SRAM.
• Burst access support using conventional asynchronous SRAM.
• Additional back-end interface bus for on-chip and off-chip logic and register access.
• Back-end interface supports user device with various wait states.
• Burst access support including MPC8260 extended transfer size.
• Write buffer supports write posting for the back-end bus interface.
• Handles separate address bus and data bus tenure.
• Supports PowerPC address pipeline for improve performance.
• Supports address bus retry generated by other external device.
• Qualified address data bus grant through the use of bus busy signals.
