Silicon Creations provides precise, ultra-low jitter LC-tank based PLLs for demanding applications such as AFE, Converter, high-end PHY and RF clocking. Our LC-PLL portfolio includes:
- Advanced Fractional-N LC-PLLs with all digital architecture supporting an LC-Tank are proven in 7nm FinFET and commencing production. These IPs are low power (below 10mW), small (below 0.1mm2) and can provide broadband jitter comfortably below 300fs RMS.
- 28nm Fractional-N synthesizers in production in TSMC, UMC and SMIC with generated LTJ below 500fs RMS broadband and below 150fs RMS integrated above 1MHz.
