The I3C Device Controller IP Implements Device Controller functionality as defined by the MIPI Alliance’s I3C Specification. The I3C bus is used for various sensors in the mobile/automotive system where an I3C Host Controller transfers data and control information between itself and various sensor devices. The I3C Device Controller IP can be easily integrated into the Sensor/Device Controllers with minimal gate count.
The I3C Device Controller is highly configurable (synthesis time) to provide an optimal solution based on the Device’s requirements. This includes, acting as a legacy I2C device, Support for Dynamic Address Assignment, HDR, and a configurable FIFO for data transfers. In addition, Optional I3C Device Controller functions like Interrupt generation, Hot-Join request generation. The I3C Device Controller IP provides direct signaling to connect to the IO Buffers (SCL and SDA).
