Vendor: Silicon Library Inc. Category: Single-Protocol PHY

SD4.x UHSII

SLI UHS-II PHY Analog IP consists of a mixed-signal SERDES supporting both Full Duplex and Half Duplex modes.

PHY View all specifications

Overview

Silicon Library (SLI) SDHC/SDXC UHS-II PHY IP solution, which consists of analog PHY IP module and digital Physical Coding Sublayer (PCS) IP module, is compliant with SD 4.1 standard. PHY analog IP is provided as a hard macro, and PCS IP is provided as a synthesizable soft macro.

SLI UHS-II PHY Analog IP consists of a mixed-signal SERDES supporting both Full Duplex and Half Duplex modes. The data rate covers from 390Mbps to 1.56Gbps (Full Duplex) / 3.12Gbps (Half Duplex). This IP can be configured as either Host applications such as DSC and SD Card readers, or Device applications including SD Cards.SLI UHS-II PCS IP supports both 8bit and 16bit interfaces for the link layer to provide the flexibility of user implementation. Loopback modes, Built-In-Self-Test (BIST) and other test modes are available for customer’s SoC and system tests.

This IP is available as Silicon proven ‘off-the-shelf’ IP in various major fabs and technology nodes from 6nm to 130nm. Please download the product brief or contact sales for more detailed information. SLI will accept porting requests from customers.

Key features

PHY Features

  • SD 4.1 standard compliant physical layer
  • Supports either UHS-II host or device
  • 156MB/s (Full-Duplex), 312MB/s (Half-Duplex)
  • Programable analog characteristics

PCS Features

  • SD 4.1 standard compliant physical coding sublayer
  • Fully synthesizable RTL
  • 8bit and 16bit interfaces with link layer
  • Power saving modes
  • Test mode control
  • Analog characteristics control

Block Diagram

Click to open fullscreen

Specifications

Identity

Part Number
SD4.x UHSII
Vendor
Silicon Library Inc.
Type
Silicon IP
Controller / PHY
PHY

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
