Vendor: Dolphin Semiconductor Category: ESD Protection

Over-voltage Protection Module to handle direct connection of voltage regulators to a 5V battery using standard 1.8V devices

Over-voltage Protection Module to handle direct connection of voltage regulators to a 5V battery using standard 1.8V IO devices

GlobalFoundries 22nm FDX Pre-Silicon View all specifications

Overview

Over-voltage Protection Module to handle direct connection of voltage regulators to a 5V battery using standard 1.8V IO devices

Key features

  • Allows direct connection of voltage regulators to a 5V battery using standard 1.8V IO devices
  • Low-quiescent for best consumption in sleep & deep sleep modes

Block Diagram

OPM-G2-1.9-5.5-1.8.01_GF_22_FDX block diagram

Silicon Options

Foundry Node Process Maturity
GlobalFoundries 22nm FDX Pre-Silicon

Specifications

Identity

Part Number
OPM-G2-1.9-5.5-1.8.01_GF_22_FDX
Vendor
Dolphin Semiconductor
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Learn more about ESD Protection IP core

How to specify and integrate successfully a measurement analog front-end including its power computation engine in an energy metering IC

Based on the system specification of a typical smart meter, this article demonstrates the importance of carefully selecting the power metering IP solution so that its specification matches the standard requirements and copes with the application challenges. This article then pinpoints thoroughly the various issues that must be taken into account for the selection of the Silicon IP and helps identify the possible trade-offs between the performance of the Mixed-signal Front-end (MFE) and that of the Power and energy Computation Engine (PCE).

Frequently asked questions about ESD Protection Library IP cores

What is Over-voltage Protection Module to handle direct connection of voltage regulators to a 5V battery using standard 1.8V devices?

Over-voltage Protection Module to handle direct connection of voltage regulators to a 5V battery using standard 1.8V devices is a ESD Protection IP core from Dolphin Semiconductor listed on Semi IP Hub. It is listed with support for globalfoundries Pre-Silicon.

How should engineers evaluate this ESD Protection?

Engineers should review the overview, key features, supported foundries and nodes, maturity, deliverables, and provider information before shortlisting this ESD Protection IP.

Can this semiconductor IP be compared with similar products?

Yes. Buyers can compare this product with similar semiconductor IP cores or IP families based on category, provider, process options, and structured technical specifications.

×
