UDP 100G / 40G / 25G / 10G / 1G IP core

UDP100G/40G/25G/10G/1G IP core is the epochal solution implemented without CPU. This IP core is suitable for network application. This IP product includes reference design for AMD FPGA. It helps you to reduce development time.

• All hardware logic to achieve CPU-less system
• Support IPv4 protocol
• Support one port connection
• Transmit/Receive buffer size, programmable on HDL for optimized resource
• Simple data interface by standard FIFO interface
• Simple control interface by standard register interface
• Multicast/broadcast Tx feature customization
• 19.2ns Super low-latency DG 10G25G EMAC-IP for UDP25G/10G-IP core (Option)
• Provide free evaluation bit file for FPGA Development Kits (1 hour time limited)
• Reference design is included in IP core product
