10M Verification IP

The 10M Ethernet Verification IP provides an effective & efficient way to verify the components interfacing with Ethernet interface of an IP or SoC. The 10M Ethernet VIP is fully compliant with IEEE standard 802.3 specification. This VIP is light weight with easy plug -and- play interface so that there is no hit on the design cycle time.

• Supports standard MII (Media Independent Interface) interface.
• Supports Full Duplex operation.
• Supports MMD block in all Physical sub-layers.
• Provides STA controller to configure the MMD blocks.
• Supports all types of error injection and detection.
• On-the-fly protocol checking using protocol check functions.
• Performs Clock Data Recovery (CDR) operation on incomingdata from below Sub-layer.
• Provides configuration in monitor for both error injection andnormal test cases.
• Provides scoreboard for endpoint verification.
• Supports clock and data recovery for all Phy sublayers.
• Provides local loopback & Remote Loopback to/from theservice interfaces.
• Supports Jabber functionalities.
• Supports AUI in normal mode of operation.
• Supports the sending of carrier sense and SQE(signal qualityerror) to the MAC sublayer.
• Supports PLS_PMA (DTE_MAU) interface protocol across AUI.
• Supports Manchester encoding and control encoding totransmit data across AUI.
• Supports the detection of the presence of two or more stationsconcurrent transmissions.
• Supports Data clocking and Timing control between the DTEand physical medium.
• Supports link integrity monitoring for reliable data transmission.
• Callbacks in RS and Phy layers to provide user control.
• Graphical Protocol layer analyzer shows Ethernet data foreasy debugging

• Available in native SystemVerilog (UVM/OVM/VMM) and Verilog.
• Unique development methodology to ensure highest levels of quality.
• Availability of various Regression Test Suites.
• 24X5 customer support.
• Unique and customizable licensing models.
• Exhaustive set of assertions and cover points with connectivity example for all the components.
• Consistency of interface, installation, operation and documentation across all our VIPs.
• Provide complete solution and easy integration in IP and SoC environment.

• 10M Ethernet Master/Slave
• 10M Ethernet BFM/Agents for :
  • MAC Layer
  • PLS Layer
  • MAU Layer of Base T
• 10M Ethernet Layered Monitor and Scoreboard
• Integration Guide, User Manual and Release Notes
• Test Environment & Test Suite :
  • Basic and Directed Protocol Tests
  • Random Tests
  • Error Scenario Tests
  • Coverage Tests
  • User Test Suite
