FlexRay Controller

The vendor has designed FlexRay RTL IP Core, supporting data rate up to 10 Mbps.

Contact Provider Request Datasheet

Overview

The vendor has designed FlexRay RTL IP Core, supporting data rate up to 10 Mbps.

FlexRay, a high-speed protocol for advanced vehicles, addresses safety-critical features, surpassing CAN limitations. Essential in modern automotive tech, it caters to the growing demand for high-end performance.

Key features

  • Flexray is more reliable compared to CAN, LIN.
  • Flexray is more faster compared to CAN, LIN.
  • High data rates.
  • Flexible configuration.
  • Collision free access.
  • Versatile topology options.
  • Fault-tolerant.
  • Event and time triggered.
  • Can consist of 'n' number of nodes.
  • Dual-channel system.

Block Diagram

FlexRay Controller block diagram

Benefits

  • The CAN BUS protocol is known as message based protocol. In this type of protocol nodes on the bus have no identifying information so it is very easy to insert or delete it from network without any updating on software or hardware systems.
  • CAN provides broadcast message transmission so all nodes in the network can see all transmitted messages and it is nodes decision to accept or filter out.
  • CAN Protocol has many applications in automobile sector, medical devices and industrial automation.

Specifications

Identity

Part Number
FlexRay Controller
Vendor
Logic Fruit Technologies
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Contact Logic Fruit Technologies
