Ethernet - up to 800G Verification IP

The 10/100/1G/2.5G/5G/10G/40G/100G/200G/400G/800G Ethernet Verification IP is compliant with IEEE 802.3 specifications and verifies MAC-to-PHY and PHY-to-MAC layer interfaces of designs with a 10/100/1G/2.5G/5G/10G/25G/40G/50G/100G/200G/400G/800G Ethernet interface. It can work with SystemVerilog,Vera, SystemC, E and Verilog HDL environment. Ethernet Verification IP is developed by experts in Ethernet, who have developed ethernet products in companies like Intel, Cortina-Systems, Emulex, Cisco. We know what it takes to verify a ethernet product.

Ethernet - up to 800G Verification IP is supported natively in SystemVerilog, VMM, RVM, AVM, OVM, UVM, Verilog, SystemC, VERA, Specman E and non-standard verification env

Ethernet - up to 800G Verification IP comes with optional Smart Visual Protocol Debugger (Smart ViPDebug), which is GUI based debugger to speed up debugging.

• Supports 2.5G and 5G Speeds as per 802.3cb
• 2.5GBASE-KX
• 5GBASE-KR
• 2.5GBASE-T
• 5GBASE-T
• Supports 200G and 400G Speeds as per 802.3bs
• 200GBase_KR8
• 200GBase_KR4
• 200GBase_KR2
• 400GBase_KR4
• 400GBase_KR8
• 400GBase_KR16
• Supports CDAUI_16
• Supports CDMII
• Supports FEC
• Supports scrambler
• Supports backplane auto-negotiation
• Supports 800G Speeds as per 802.3bs
• 800GBase_KR16
• Supports 800GMII
• Supports Reed - Solomon FEC
• Supports scrambler
• Supports backplane auto-negotiation
• Supports 100G as per 802.3ba and 802.3bj
• Supports CGMII
• Supports 100GBase-KR10/100GBase-CR10/100GBase-SR10
• Supports 100GBase-ER4/100GBase-LR4
• Supports 100GBase-KR4
• Supports 100GBase-KR2
• Supports 100GBase-KR
• Supports 100GBase-R
• Supports 100GBASE-KP4 with PMA enable.
• Supports Gray coding and Precoding as per Spec IEEE 802.3
• Supports CAUI_4
• Supports RS_FEC(clause 91)
• Supports scrambler
• Supports backplane auto-negotiation
• Supports 40G as per 802.3ba
• Supports XLGMII
• Supports 40GBase-KR4/40GBase-CR4/40GBase-SR4/40GBase-LR4
• Supports FEC
• Supports scrambler
• Supports backplane auto-negotiation
• Supports 25G and 50G Speeds
• 25GBase_R
• 25GBase_KR
• 50GBase_KR
• 50GBase_KR2
• Supports FEC
• Supports scrambler
• Supports backplane auto-negotiation
• Supports 10G as per 802.3
• Supports XGMII
• Supports XTBI (i.e Output of 8b/10b PCS)
• SUpports XAUI, RXAUI and 10GBASE-KX4
• Supports 10GBASE-KR with scrambler
• Supports FEC for 10GBase-KR
• Supports USXGMII
• Supports scrambler
• Supports backplane auto-negotiation for 10GBase-KX4 and 10GBase-KR
• Supports 1G
• Supports GMII
• Supports TBI (i.e Output of 8b/10b PCS)
• Supports SGMII/SGMII_TBI as per specification 1.8
• Supports QSGMII as per specification 1.2
• Supports USGMII as per specification 3.0 and 3.1(5G and 10G)
• Supports RGMII/RTBI as per specification 2.0
• Supports 1000Base-KX
• Supports 1GBASE-SX and 1GBASE-LX
• Supports clause 73 backplane auto-negotiation for 1000Base-KX
• Supports clause 37 auto-negotiation
• Supports SGMII auto-negotiation
• Supports QSGMII auto-negotiation
• Supports USGMII auto-negotiation and packets
• Supports full duplex and half duplex of operation
• Supports 100M
• Supports MII
• Supports SMII as per specification 2.1
• Supports RMII as per specification 1.2
• Supports 100BASE-FX
• Full support for IEEE 1588-2002 and IEEE 1588-2008
• Full support for IEEE 802.3BG
• Full support for IEEE 802.1AZ (Energy Efficient Ethernet)
• Supports the following TSN protocols:
• Full support for IEEE 802.1BA
• Full support for IEEE 802.1Qat
• Full support for IEEE 802.1Qav
• Full support for IEEE 802.1Q
• Full support for IEEE 802.1AS
• Full support for IEEE 802.1Qbv
• Full support for IEEE 802.1Qbu
• Full support for IEEE 802.1Qca
• Full support for IEEE 802.1CB
• Full support for IEEE 802.1Qcc
• Full support for IEEE 802.1Qci
• Full support for IEEE 802.1Qch
• Full support for IEEE 802.1CM
• Full support for IEEE 802.1Qcr
• Full support for IEEE 802.1CS
• Full support for IEEE 802.3br
• Supports G.999.1 interface
• Ethernet Verification IP comes with complete UNH Test suite
• Supports the following upper layer protocols
• IPV4
• IPV6
• TCP
• UDP
• ICMP
• ARP
• GRE
• NVGRE
• VXLAN
• PPPOE
• EAPoL
• FCOE
• RARP
• IPsec
• MACSEC
• Wake on LAN
• Slow protocol
• Supports RoCE
• Supports IP in IP
• Supports Q in Q
• Supports USXGMII
• Supports single port USXGMII as per specification 2.5
• Supports multi port USXGMII as per specification 2.2
• Forty Bit Interface (XFBI)
• XSBI Interface (16-bit)
• XSBI Interface (20-bit)
• XLSBI Interface(16X4 40 PCS Interface)
• XLSBI Interface(20X4 40 PCS Interface)
• CSBI(20 lane) Interface (8,10,16,20,32,64,80,128 bit)
• CSBI(10 lane) Interface (8,10,16,20,32,64,80,128 bit)
• CSBI(10 lane) Interface (8,10,16,20,32,64,80,128 bit)
• PCS to Serdes interface supports all widths
• Supports CDR for serial protocols
• Supports WAN Interface Sublayer (WIS), type 10GBASE-W
• Supports MDIO slave and master model as per Clause 22 and Clause 45
• Glitch insertion and detection
• Supports all types of TX and RX errors insertion/detection at each layer.
• Comes with Tx BFM, Rx BFM, and Monitor
• Monitor supports detection of all protocol violations
• Supports Pause frame generation and detection
• Built in coverage analysis
• Callbacks in master and slave for various events
• Status counters for various events in bus
• Functional safety features (B: No certification, with safety features, in line with the development process)

• Faster testbench development and more complete verification of Ethernet designs
• Easy to use command interface simplifies testbench control and configuration of TX and RX
• Simplifies results analysis
• Runs in every major simulation environment

• Complete regression suite (UNH) containing all the Ethernet testcases.
• Examples showing how to connect various components, and usage of TXRX BFM and Monitor.
• Detailed documentation of all class, task and function's used in verification env.
• Documentation also contains User's Guide and Release notes.
