GUC Announces 2nm 16 Gbps HBM4E IP
HSINCHU, Taiwan — September 22, 2026 — Global Unichip Corp. (GUC), the Advanced ASIC Leader, today announced that its HBM4E PHY and Controller IP is design-ready and has been adopted in customer AI ASICs. Implemented on TSMC's cutting-edge N2P process, the HBM4E PHY has successfully taped out on TSMC CoWoS®-L advanced packaging technology.
Building on GUC's silicon-proven 12 Gbps HBM4 IP on TSMC's N3P process, the new HBM4E IP pushes data transfer speeds up to 16 Gbps across all signed-off operating conditions while delivering industry-leading power efficiency and an ultra-compact area footprint. Leveraging GUC's proprietary interposer layout technology, the IP is fully optimized for signal integrity (SI) and power integrity (PI) across various TSMC CoWoS packaging configurations.
To power 3D SoIC architectures, GUC's HBM4E IP includes a face-up variant engineered for use as a bottom die in TSMC SoIC®-X technology. It integrates dedicated Through-Silicon Vias (TSVs) for signal pull-out and feedthrough power delivery to top dies, establishing a seamless path for complex 3D integration. In line with GUC's proven HBM, GLink, and UCIe portfolios, the HBM4E IP incorporates proteanTecs’ interconnect monitoring technology. This integration enhances visibility during PHY testing and characterization while maximizing in-field performance and system reliability.
“HBM4E marks a major leap forward in bandwidth and system-level performance for next-generation AI accelerators. Reaching 16 Gbps on TSMC's N2P process underscores GUC's ability to quickly turn leading-edge process and packaging technology into production-ready HBM solutions,” said Igor Elkanovich, CTO of GUC.
“By uniting our face-up HBM, face-up UCIe, and GLink-3D IPs, GUC delivers a complete interface IP portfolio for 3D SoIC architectures — the foundation for modern AI ASICs—enabling customers to seamlessly connect HBM, chiplets, and 3D dies that leverage the most advanced process technology.”
GUC HBM4E IP Highlights
- Ready on TSMC N2P, timing signoff at 16 Gbps
- Supports all TSMC CoWoS technologies – CoWoS-S/R/L
- Supports face-up configuration for 3D SoIC architecture
- Advanced Interposer Routing to support angle routing with a Y-dimension offset
- Supports high bandwidth utilization and advanced RS functionality for silent data corruption prevention
- Built-in proteanTecs chiplet interconnect monitoring solution
