SWI3S (SoundWire I3S Interface) Peripheral Controller Core IP

Arasan’s SWI3S (SoundWire I3S Interface) Peripheral Controller Core IP implements the link protocol to communicate in half-duplex fashion to transfer the Audio streams and the Control information together. This SWI3S Peripheral IP is a responsive, time-synchronized, and power-aware component within the SoundSire-I3S ecosystem.

SWI3S Specifications Support

• Implements & supports MIPI SoundWire-I3S Specification

Core Functional Features

• Capable of receiving timing information from Manager to
  • Send and receive data bits
  • Generate audio sampling events• Capable of Transport audio sample streams typically via
  • Multiple channels
  • PDM or PCM formats
  • Supports various sample rates- 44.1KHz, 48KHz
  • Support for Flow-Controlled transmission (sink-and-source-controlled)
  • Low-Latency transmission design (~300ns)

Control and Communication Features

• Allows Manager’s commands for the peripheral registers
• Read Status Information and communicates Interrupts
• Supports In-band signaling like wake-up requests, Interrupt conditions, and reset signaling
• Power and System Management
• Support for link-power states like sleep, wake and clock pause
• Support for request link control actions like link awake and cold boot

Protocol and Error Handling

• Support for peripheral response states for reads, writes and commits including WRITE-OK, READ-DATA-NOW, COMIT-READY etc.
• Support handling of transport protocol errors through error counters and interrupt mechanisms for the Manager

• System Verilog RTL Source Code
• A simplified Testbench with simulation models to run initial set of tests after release
• Lint Report
• Synthesizable Netlist
• Synthesis Scripts and exception lists
• Timing Report
• Protocol Compliance & Coverage Report
• Sample Firmware with Drivers
• Application Notes
