SpaceWire Verification IP

The SpaceWire Verification IP provides an effective & efficient way to verify the components interfacing with SpaceWire interface of an ASIC/FPGA or SoC. The SpaceWire VIP is fully compliant with ECSS-E-ST-50-12 C rev 1 specification of SpaceWire. This VIP is a light weight with an easy plug-and-play interface so that there is no hit on the design time and the simulation time.

• Available in UVM, System Verilog.
• Compliant to Specification ECSS-E-ST-50-12 C rev 1.
• Supports speeds between 2Mb/s to 400Mb/s
• Supports full duplex Serial data communication links
• Supports all Layers: Physical Layer, Encoding Layer, Data-link Layer, Network Layer, Management information base and service interfaces
• Supports Serialization and De-serialization.
• Supports Data-Strobe (DS) encoding and decoding
• Supports Character and control code encoding
• Supports flow control and link Initialization.
• Supports Broadcast codes, Time-codes, nodes and routing
• Supports sending packets of information from a source to a specified destination node.
• Supports encoding/decoding Link interface. Ø Supports all types of errors insertion/detection as given below:
  • Link Error
  • Network Error
  • Disconnect Error
  • ESE Error (Escape Sequence Error)
  • Character Sequence Error
  • Parity Error
  • Destination Address Error
  • Empty Packet Error
  • Credit Error
• Provides link error recovery.
• Supports the exchange of silence error recovery procedure.
• On-the-fly protocol and data checking.
• Notifies the test bench of significant events such as transactions, warnings and protocol violations.
• Status counters for various events on bus.
• Built in functional coverage analysis.
• SpaceWire Verification IP comes with complete testsuite to verify each and every feature of SpaceWire specification.
• Provides full control to the user to enable / disable various types of messages.
• Supports Dynamic as well as Static Error Injection scenarios.
• On the fly protocol checking using protocol check functions, static and dynamic assertion.
• Built in Coverage analysis.
• Provides a comprehensive user API (callbacks) in Transmitter and Receiver.
• Graphical analyzer to show transactions for easy debugging.

• Available in native System Verilog (UVM/OVM/ VMM) and Verilog
• Unique development methodology to ensure the highest levels of quality
• Availability of Compliance & Regression Test Suites
• 24X5 customer support
• Unique and customizable licensing models
• Exhaustive set of coverage points with connectivity example for all the components
• Consistency of interface, installation, operation, and documentation across all our VIPs
• Provide complete solution and easy integration in IP and SoC environment

• SpaceWire Transmitter

• SpaceWire Receiver

• SpaceWire Monitor

• SpaceWire Scoreboard

• Basic Test Suite

• Error Test Suite

• User Test Suite

• Integration Guide, User Manual and Release Notes
