DC/DC buck converter in GF 22FDX with low quiescent current and high efficiency at light load

DC/DC buck converter in GF 22FDX with low quiescent current and high efficiency at light load.

Contact Provider Request Datasheet
GlobalFoundries 22nm FDX Pre-Silicon View all specifications

Overview

DC/DC buck converter in GF 22FDX with low quiescent current and high efficiency at light load.

Key features

  • Low quiescent current to ensure minimum current consumption in deep sleep mode.
  • High efficiency at light load to extend battery lifetime (74% @ 10 uA)
  • Low ripple value to supply noise sensitive and RF loads
  • 1 uH inductor
  • Configurable output current (depending on application requirements)

Block Diagram

DCDC-ULP-22FDX-1.8-5.5-0.5-3.3.01a_GF_22_FDX block diagram

Silicon Options

Foundry Node Process Maturity
GlobalFoundries 22nm FDX Pre-Silicon

Specifications

Identity

Part Number
DCDC-ULP-22FDX-1.8-5.5-0.5-3.3.01a_GF_22_FDX
Vendor
Dolphin Semiconductor
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Contact Dolphin Semiconductor
