Vendor: StarFive Category: CPU

High-performance, commercial-grade RISC-V CPU Core IP

Commercial-grade 64-bit RISC-V CPU IP that is RVA23 Profile compliant, supports Vector and Vector Crypto extensions, and enables high-performance applications.

RISC-V 64-bit View all specifications

Overview

Dubhe-100 is a commercial-grade 64-bit RISC-V CPU IP that is RVA23 Profile compliant, supports Vector and Vector Crypto extensions, and enables high-performance applications.

Design Specifications

  •  SPECint2006: 15/GHz
  •  Dhrystone v2.2: 10.0/MHz (Legal)
  •  ISA：RV64GCBVH
  •  15-stage pipeline, 6-issue
  •  Superscalar, deep out-of-order execution
  •  Support Multi-core cache coherence
  •  Support instruction fusion
  •  Support AIA1.0

Key features

HPM

  • RISC-V standard HPM support
  • Micro-architecture level analysis and performance tuning

PMP&PMA

  • Configurable 16/32/64 PMP supported regions, minimum 4096-byte region size
  • Support predefined PMA and Svpbmt

Debug & Trace

  • Standard debug module compliant with RISC-V Debug Spec
  • Standard Trace module interface compliant with RISC-V Trace Spec

Power Management

  • Core-level WFI mechanism
  • Core/cluster-level clock gating
  • Core/cluster-level low-power states: ON/OFF/Retention
  • Cluster-level frequency scaling

TKU

  • 512-entry 6-way decode/rename/commit ROB
  • 256-entry integer physical register file
  • 256-entry floating-point/Vector physical register file

VPU

  • 8/16/32/64-bit integer, IEEE754-2008-standard 16/32/64-bit floating-point and BF16 floating-point operations
  • VLEN=2*DLEN=256
  • 2 vector pipeline units
  • 2 floating-point pipeline units, sharing VPU

IFU

  • Instruction fetch decoupled from branch prediction
  • Fetch width: 32 bytes per cycle
  • RAS predictor for return instructions
  • IJTP predictor for indirect-jump instructions
  • TAGE-style predictor for conditional branch instructions

MMU

  • Bare, Sv39, and Sv48 modes defined by RISC-V Priv. Spec
  • 16-entry fully associative L1 ITLB
  • 64-entry fully associative L1 DTLB
  • 128-entry 5-way set associative STLB
  • Configurable parit check

Software Development

  • Bare Metal SDK: GCC/LLCM toolchains; GDB; pre-built OpenOCD; example projects
  • Linux SDK: Yocto-based; Kernel 6.18; OpenSBI; UBoot; host development tools
  • StarFive StarStudio (pre-built IDE)

Block Diagram

Click to open fullscreen

Applications

  • AI & Intelligent Computing
  •  HPC & Data Center
  • Intelligent  Edge & Infrastructure

Specifications

Identity

Part Number
Dubhe-100
Vendor
StarFive
Type
Silicon IP

Compute

CPU Architecture
RISC-V
Word Length
64-bit

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

StarFive
HQ: China
