ARC HS45D 32-bit, dual-issue processor core, ARCv2DSP ISA, with 100+ DSP instructions for embedded applications
The ARC® HS45D and HS47D processors feature a dual-issue, 32-bit, RISC + DSP architecture for use in embedded applications where …
Overview
The ARC® HS45D and HS47D processors feature a dual-issue, 32-bit, RISC + DSP architecture for use in embedded applications where high-performance and high clock speed plus signal processing are required. The cores can be clocked at up to 1.9 GHz in 16ff processes (worst case, single core, base configuration) and offer outstanding performance delivering 3.0 DMIPS/MHz and 5.2 CoreMark/MHz with a small area footprint and low power consumption.
The processors are based on the advanced ARCv2DSP instruction set architecture (ISA) and pipeline, which provides leading performance-efficiency and code density, and more than 150 DSP instructions. For applications requiring higher performance, dual- and quad-core versions of the HS45D and HS47D cores are available.
The ARC HS45D features close coupled memory (CCM) and is optimized for use in applications where real-time, deterministic behavior is required. The HS47D is designed for high-performance embedded applications that require cache and includes all of the features of the HS45D plus support for up to 64K Level 1 (L1) instruction and data cache.
The processors are designed to be used in applications such as wireless baseband, voice/speech processing, home audio, automotive systems, and other high-end embedded applications that require signal processing.
Key features
- Combination Dual-issue, 32-bit RISC + DSP processor
- Delivers up to 5700 DMIPS and 9880 CoreMark per core at 1.9 GHz on 16ff (worst case conditions, single-core configuration)
- ARCv2DSP ISA adds over 150 DSP instructions
- Easy DSP programming support with Metaware C/C++ Compiler
- Feature-rich DSP software library for easy algorithm programming
- One 32x32, Two 16x16, or two dual 16x16 MACs/cycle
- Fixed point, vector/SIMD DSP processing support
- Based on advanced ARCv2 ISA
- Support for custom instructions
- Support for up to 16MB of close coupled memory and direct mapping of peripherals
- Dual- and quad-core versions for higher performance
Block Diagram
dwc_arc_hs45d_core block diagram
Specifications
Identity
Part Number
dwc_arc_hs45d_core
Vendor
Synopsys, Inc.
Type
Silicon IP
Compute
CPU Architecture
ARC
Files
Note: some files may require an NDA depending on provider policy.
Provider
HQ:
USA
