What is 40nm 1.1V 6.0GHz-9.4GHz Fractional-N RF PLL?
40nm 1.1V 6.0GHz-9.4GHz Fractional-N RF PLL is a PLL IP core from Tetrivis listed on Semi IP Hub. It is listed with support for tsmc.
Vendor:
Tetrivis
Category:
PLL
40nm 1.1V 6.0GHz-9.4GHz Fractional-N RF PLL
The TRV303TSM40LP IP is a 1.1V low-power, low-silicon-area and high-performance 6.0GHz-to-9.4GHz Fractional-N RF PLL implemented …
Overview
The TRV303TSM40LP IP is a 1.1V low-power, low-silicon-area and high-performance 6.0GHz-to-9.4GHz Fractional-N RF PLL implemented in TSMC Low-Power 40nm CMOS process technology. Its low loop-filter bandwidth and low phase-noise characteristics makes it especially suitable for use in on-chip Local Oscillator References for Tx and Rx up/down-converters within wireless communication and Internet-of-Things integrated circuit chipsets (LTE, WiFi, IoT, etc).
Key features
- 6.0GHz-to-9.7GHz Buffered VCO PLL Output Coverage
- Scalable Power Consumption
- Internal Calibration Engine and Convergence Algorithm
- Fully-integrated 300kHz loop filter
- 20MHz to 54MHz Crystal Oscillator Reference Support
Block Diagram
TRV303TSM40LP block diagram
Benefits
- Low-power and low-area fully-featured 6.0GHz-to-9.4GHz Fractional-N RF PLL with integrated calibration engine and tuning voltage convergence logic.
Applications
- The PLL is suitable for use in on-chip Local Oscillator References for Tx and Rx up/down-converters within wireless communication and Internet-of-Things integrated circuit chipsets (LTE, WiFi, IoT, etc).
What’s Included?
- Behavioural Models
- Timing Models
- GDSII Layout Database
- Netlist for LVS verification
- Usage and Integration Guidelines
- Databook
Silicon Options
| Foundry | Node | Process | Maturity |
|---|---|---|---|
| TSMC | 40nm | G | — |
Specifications
Identity
Part Number
TRV303TSM40LP
Vendor
Tetrivis
Type
Silicon IP
Files
Note: some files may require an NDA depending on provider policy.
Provider
HQ:
United Kingdom
