Vendor: M31 Technology Corp. Category: PLL

10~240MHz in, 1.5GHz, Integer PLL, TSMC 28HPC+, N/S orientation

Low Power Fractional PLL is a general purpose frequency synthesizer with an input reference frequency range from 10 to 240 MHz an…

Contact Provider Request Datasheet
TSMC 28nm HPC+ View all specifications

Overview

Low Power Fractional PLL is a general purpose frequency synthesizer with an input reference frequency range from 10 to 240 MHz and 3:1 output frequency range. The PLL core is a typical Type-II PLL and the fractional portion of the output frequency is achieved by using a programmable 3rd-ord sigma delta modulator. The PLL core operates on IO supply voltage for excellent supply rejection in noisy SoC applications. It is designed for easy usage and simple integration, eliminating the need for complex configurations.

Key features

  • Supports wide input frequency range: 10MHz to 240MHz
  • Supports 3:1 output frequency range allows optimization for power and jitter performance
  • 24-bit fractional accuracy
  • Supports Spread Spectrum Clocking
  • Lock Detect Signal indicates when frequency lock is achieved
  • Embedded frequency meter circuit for mass production testing
  • Embedded continuous monitoring watchdog circuit for automotive applications
  • Output mux for bypass mode
  • PLL Core Area less than 100µm x 100µm @22nm
  • Low Power Consumption, less than 1.0mA from IO voltage domain at lowest output frequency operation

Block Diagram

10~240MHz in, 1.5GHz, Integer PLL, TSMC 28HPC+, N/S orientation block diagram

Silicon Options

Foundry Node Process Maturity
TSMC 28nm HPC+ —

Specifications

Identity

Part Number
10~240MHz in, 1.5GHz, Integer PLL, TSMC 28HPC+, N/S orientation
Vendor
M31 Technology Corp.
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Contact M31 Technology Corp.
