Vendor: Corepilot Category: USB

USB Controller

Supports full protocol coverage from USB 2.0 to USB 3.2 Certified by USB-IF

Controller USB 3.2 + 1 View all specifications

Overview

Corepilot provides ASIC and FPGA solutions for USB controller IP, featuring high performance, low power consumption, small area, flexible configuration and strong compatibility. Supports USB 3.2/3.1/3.0/2.0 speeds, Host/Device/Dual-role modes and eUSB. We are the first domestic and second worldwide IP vendor to obtain the official 10Gbps certification from the USB Implementers Forum.The team boasts extensive IP technical support experience and offers customized design services for various USB applications, effectively shortening the time for customer integration, verification and silicon bring-up testing. Corepilot’s USB controller IP has been adopted by numerous customer projects both at home and abroad, is compatible with mainstream market PHY IP, and has been shipped in over 100 million chips.

Key features

  • Supports USB 3.2/3.1/3.0/2.0 speeds (20G/10G/5G/480M bps)
  • Compatible with standard drivers
  • Supports PIPE v4.3 protocol and various data bus widths
  • Supports embedded DMA
  • Supports AXI3/AXI4 interfaces with configurable data bus widths
  • Supports automatic link polarity detection and inversion
  • USB 3.x supports U1/U2/U3 low-power states
  • USB 2.0 supports L1/L2 low-power states
  • USB 2.0 supports hardware LPM and BESL
  • Supports MSI/MSI-X and Legacy interrupts
  • Supports Debug Capability
  • Supports bulk streaming transfer
  • Supports UTMI+/ULPI interfaces with various data bus widths
  • Supports register access interfaces including AXI/AHB/APB
  • Configurable number of interrupt sources
  • Configurable number of slots
  • Configurable number of IN/OUT endpoints
  • Configurable RX and TX buffer sizes
  • Configurable bandwidth and latency combinations
  • DMA supports Scatter-and-Gather memory access
  • Supports descriptor and data prefetching to improve transfer efficiency
  • Configurable number of ports
  • Supports all transfer types: control, bulk, interrupt, and isochronous

Block Diagram

Click to open fullscreen

Applications

  • Consumer Electronics
  • Storage Devices
  • Video/Image Processors
  • Automotive Electronics

Specifications

Identity

Part Number
USB Controller
Vendor
Corepilot
Type
Silicon IP
Controller / PHY
Controller

Standards & Interfaces

USB Standard
USB 3.2 , USB 2.0

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Corepilot
HQ: China
