USB 1.1 Device Controller version 4 with Active Clock Gating to save active power
The high-quality, silicon-proven USB 1.1 Controller IP enables designers to implement a host and/or device into their SoC designs.
Overview
The high-quality, silicon-proven USB 1.1 Controller IP enables designers to implement a host and/or device into their SoC designs. By utilizing the compliant USB 1.1 Controller IP solution, designers can leverage these solutions to significantly reduce development time and engineering risk while bringing their USB-based products to market faster. The USB 1.1 Controllers consist of the USB 1.1 OHCI Host and Device.
The vendor optimized the USB 1.1 OHCI Host and Device controllers for low power, small area and ease-of-integration, for use in Internet-of-Things (IoT) applications. Designers save time and effort through rapid configuration. The USB 1.1 OHCI offloads the system bus and MCU, reducing the interrupts, MIPS, and power consumed in the system. The OHCI register set makes the controller compatible with OHCI host stacks and drivers available on most major operating systems.
The USB IP is the most certified IP solution in the industry. With thousands of design wins and billions of silicon-proven units shipped, the vendor's complete USB IP solution, consisting of digital controllers, PHY and Verification IP, enables designers to lower integration risk and speed time-to-market.
Key features
- Silicon-proven
- USB 1.1 compliant
- Lowest gate count, lowest area
- Optimized power management
- Supports low- and full-speed devices
Block Diagram
dwc_usb_1_1_device_v4 block diagram
Specifications
Identity
Part Number
dwc_usb_1_1_device_v4
Vendor
Synopsys, Inc.
Type
Silicon IP
Provider
HQ:
USA
