MIPI DPHY-Tx

Complete PHY solution that is fully compliant to MIPI D-PHY specification version 1.2

PHY MIPI D-PHY GlobalFoundries 55nm LPe Available on request View all specifications

Overview

Silicon Library (SLI) MIPI® D-PHY TX IP is a complete PHY solution that is fully compliant to MIPI D-PHY specification version 1.2, enabling easy integration of MIPI® D-PHY interface into low-power modern SoCs. The solution consists of Analog PHY and digital Control and Interface Logic (CIL). PHY is provided as a hard macro supporting high-speed data rates up to 2.5Gbps, while CIL is provided as a synthesizable soft macro. This IP solution can be applied to both MIPI® Camera Serial Interface (CSI-2) and MIPI® Display Serial Interface (DSI) protocols. Both High-Speed (HS) and Low-Power (LP) mode are supported with one Clock Lane and four Data Lanes.

This IP is available as Silicon proven ‘off-the-shelf’ product in TPSco 65nm.

Key features

  • Compliant with MIPI D-PHY ver1.2
  • Supports MIPI standard PHY Protocol Interface (PPI)
  • Supports both HS mode (from 80Mbps to 2.5Gbps) and LP mode (up to 10Mbps)
  • Supports unidirectional four data lanes
  • Supports unidirectional clock lane
  • Configurable lanes for either data or clock
  • Skew calibration sequence
  • 8:1 serializer
  • Integrated at-speed BIST(Built-In Self-Test)
  • Supports transmitter DC test, IDDQ test
  • Programmable analog characteristics

Block Diagram

Click to open fullscreen

Silicon Options

Foundry Node Process Maturity
GlobalFoundries 55nm LPe Available on request

Specifications

Identity

Part Number
MIPI DPHY-Tx
Vendor
Silicon Library Inc.
Type
Silicon IP
Controller / PHY
PHY

Standards & Interfaces

MIPI PHY
MIPI D-PHY
