JPEG Encoder 1-pixel/clock

- Baseline JPEG encoder/decoder described in RTL compliant with ISO/IEC 10918-1 - High speed processing with low clock frequency …

Contact Provider Request Datasheet

Overview

- Baseline JPEG encoder/decoder described in RTL compliant with ISO/IEC 10918-1

- High speed processing with low clock frequency

- Suitable for digital still camera .printer,facsimile and surveillance camera system

- 3 types of IPs are available.
Pixel/clock@4:2:2: 1, Performance (4K2K-fps@100MHz) 12.5 fps
Pixel/clock@4:2:2: 4, Performance (4K2K-fps@100MHz) 50 fps
Pixel/clock@4:2:2: 8, Performance (4K2K-fps@100MHz) 100 fps

Key features

  • - Image Format: Frame sequential method
  • - Input/Output Format: YUV 4:4:4/4:2:2/4:2:0/4:0:0
  • - Data bus protcol: AXI
  • - CPU bus protcol: AHB
  • - Error detection during decoding illegal stream
  • - Tables
    • (encode) Quantization table:2(Programmable)
      • Huffman table :4(*Programmable)
      • *:option only of 1pixle/clock
    • (decode) Quantization table:4
      • Huffman table :4
    • - Scaling function of Quantization table
    • - SOI,DHT,DQT,DRI,SOF0,SOS,RSTm,EOI

Benefits

  • TMC's DMNA (Digital Media New Algorithm), our original mathematical algorithm, drastically reduces the total amounts of calculations & operations, and realizes high-speed processing, high-quality image output, and low power consumption.

Applications

  • #NAME?

What’s Included?

  • Encrypted RTL
  • Datasheets
  • Verification environment
  • Synthesis constraint
  • Bit accurate model

Specifications

Identity

Part Number
TM20195
Vendor
Techno Mathematical Co., Ltd.
Type
Silicon IP

Provider

Contact Techno Mathematical Co., Ltd.
