HDLC frame to APB bridge
HDLC frame to APB bridge , is cable of receive and transmit of HDLC frame .
Overview
HDLC frame to APB bridge , is cable of receive and transmit of HDLC frame .
The module is accessed through an APB slave from the host side.
Key features
- Synchronous operation
- 8-bit parallel back-end interface
- Use external RX and TX clocks
- Start and end of frame pattern generation
- Start and end of frame pattern checking
- Idle pattern generation and detection (all ones)
- Zero insertion and removal for transparent transmission
- Abort pattern generation and checking (7 ones)
- Address insertion and detection by software
- CRC generation and checking (CRC-16 or CRC-32 can be used, which is configurable at the code top level)
- Configurable size FIFO buffers for low latency transfer
- Byte aligned data (if data is not aligned to 8-bits, error signal is reported to the backend interface)
- Q.921, LAPD, and LAPB compliant
- APB slave interface for host operations
Block Diagram
HDLC 2 APB Bridge block diagram
Applications
- Communication controllers in networking and telecommunication systems.
- Automotive systems for reliable data transfer (e.g., over CAN or LIN gateways).
- Industrial automation requiring HDLC connectivity with APB-based processors.
Specifications
Identity
Part Number
HDLC 2 APB Bridge
Vendor
gSOC Solutions
Type
Silicon IP
Files
Note: some files may require an NDA depending on provider policy.
