Ethernet 40G,100G Verification IP

The 40G/100G Ethernet Verification IP provides an effective & efficient way to verify the components interfacing with Ethernet interface of an IP or SoC.

The 40G/100G Ethernet VIP is fully compliant with IEEE standard 802.3-2018 specification. This VIP is lightweight with an easy plug-and-play interface so that there is no hit on the design cycle time.

• Provides 40G as perIEEE standard 802.3-2018 specification
  • Supports Ethernet XLGMII
  • Supports FEC, PCS, AN, and XLAUI
  • Supports KR4 & Cr4
• Provides 100G as per IEEE standard 802.3-2018 specification
  • Supports CGMII
  • Supports FEC/RS-FEC
  • Supports PCS, AN
  • Supports KR4, CR4 & CR10
  • Supports CAUI-n
• Supports Energy Efficient Ethernet.
• Supports all possible widths for PCS to Serdes interface.
• Supports clock data recovery(CDR).
• Supports Pause Frame-Based Flow Control.
• Supports test pattern generation and checking.
• Supports Management data Input/output registers.
• Supports full-duplex operation.
• Supports PMD training Protocol
• Callback support in all Layers to provide user control.
• Rich set of configurations and parameters.
• Supports Dynamic as well as Static Error Injection scenarios.
• On the fly protocol checking static and dynamic assertion.
• Built-in Coverage analysis.
• Graphical analyzer to show transactions for easy debugging.

• Available in native System Verilog (UVM/OVM/ VMM) and Verilog
• Unique development methodology to ensure the highest levels of quality
• Availability of Compliance & Regression Test Suites
• 24X5 customer support
• Unique and customizable licensing models
• Exhaustive set of assertions and coverage points with connectivity example for all the components
• Consistency of interface, installation, operation, and documentation across all our VIPs
• Provide complete solution and easy integration in IP and SoC environment

• Ethernet 400G/200G BFM's for
  • MAC layer
  • Reconciliation layer
  • PCS Layer
  • PMA layer
  • FEC layers (RS-FEC, BASE-R FEC)
  • PMD layer
  • AN layer
• Ethernet 40G/100G layered monitors and scoreboard
• Test Environment & Test Suite :
  • Basic and Directed Protocol Tests
  • Random Tests
  • Error Scenario Tests
  • Assertions & Cover Point Tests
  • User Test Suite
• Integration guide, user manual, and release notes
• GUI analyzer to view simulation packet flow
