Perceptia Releases Design Kit for pPLL03 on Samsung Foundry 14LPU Platform

Sydney, Australia — August 24, 2026 — Perceptia Devices, a leader in high-performance clocking IP, today announced the availability of the design kit for its pPLL03 phase-locked loop IP on Samsung Foundry’s 14LPU technology node.

The pPLL03 is Perceptia’s low jitter, high-performance PLL IP core targeted at demanding SoC applications including AI accelerators, microprocessors, ADC/DAC sampling clocks, and high-speed digital subsystems. The release of the design kit enables SoC developers to efficiently incorporate the pPLL03 into their designs with full support for layout, simulation, and timing closure.

This port of our 3rd generation architecture for pPLL03 includes power conditioning circuitry to improve PLL performance and robustness in complex SoC environments.

Key technical features of the pPLL03 include:

• Output frequency range: Up to 4 GHz, supporting integer and fractional-N operation
• Peak Period Jitter: Less than 2.1% of a cycle at 4GHz (5.25ps)
• Fast lock time (400 reference clock cycles)
• Fractional output division for rapid frequency change with glitch-less transition and 6 bit fractional resolution suitable for dynamic frequency scaling
• Compact footprint: Highly area-efficient implementation with minimal analog overhead.
  • 0.0071 sq mm in Samsung 14LPU
• Robust behaviour across process, voltage, and temperature extremes

The pPLL03 supports both integer-N and fractional-N synthesis, allowing for fine-grained frequency generation. Its all-digital control interface enables easy integration with standard digital flows and software-driven configuration.

“Our goal with pPLL03 was to bring our best-in-class jitter performance with integration flexibility to Samsung Foundry 14LPU.” said Julian Jenkins, CTO at Perceptia. “This expands Perceptia’s reach to include support for Samsung Customers.”

Samsung’s fourth-generation 14nm process technology, 14LPU, delivers optimised performance and low power in a class leading 14nm generation technology. 14LPU is suited for high-performance and compute-intensive applications.

The pPLL03 design kit includes:

• Liberty (.lib) timing models
• Verilog and Verilog-A simulation models
• GDSII and LEF physical views
• CDL netlist
• Integration guidelines and layout constraints
• Comprehensive verification and characterisation data

The kit is available immediately to qualified licensees.

For licensing inquiries or to request a technical brief, contact sales@perceptia.com or visit www.perceptia.com.

Explore Perceptia Devices IP:

• Low Power All Digital Fractional-N PLL in Samsung 14LPP
• General Purpose All Digital Fractional-N PLL in Samsung 8LPP
• General Purpose All Digital Fractional-N PLL in Samsung 14LPP
• All Digital Fractional-N RF Frequency Synthesizer PLL in Samsung 14LPP

About pPLL03

pPLL03 is a compact, low-jitter phase-locked loop (PLL) IP core optimised for advanced process nodes. Delivering output clock frequencies up to 4GHz, pPLL03 is designed for use in a wide range of high-performance applications including high-performance computing, AI acceleration and timing-critical logic, it delivers superior jitter and integration flexibility. pPLL03 is especially suited for designs with many clock domains. pPLL03 enables designers to confidently implement advanced timing architectures without compromising on area or power.

About Perceptia Devices

Perceptia Devices is an IP and design services provider, based in Sydney, Australia. With a focus on PLLs and precision timing, Perceptia supports customers across a wide range of applications including wireless communications, AI/ML, data converters, IoT, and mixed-signal SoCs with high performance, low area PLLs.

For more information or to request the pPLL05 datasheet, please contact: 📧sales@perceptia.com 🌐www.perceptia.com
