Vendor: ASICFPGA Category: ISP Image Signal Processor

WDR (Shadow and Highlight Compensation Core)

ASICFPGA WDR core: All imaging devices need dynamic range correction between source and output display.

Contact Provider Request Datasheet

Overview

ASICFPGA WDR core: All imaging devices need dynamic range correction between source and output display. Conventional techniques such as gamma correction may cause degradation of image quality and produce unnatural images. Backlight compensation is done either manually or automatically to correct the exposure of subjects that are in front of a bright light source. Backlight compensation may also cause degradation of image quality and produce unnatural images. Our shadow/highlight compensation automatically calculates a different curve transformation based on an analysis of the scene content while preserving local contrast in each image pixels. Contrast and detail is preserved both in dark and bright areas. The true color is preserved and the dynamic range also is extended. The shadow/highlight compensation is a great new feature that offers the correction of the images in over- and under ex-posed areas. The shadow/highlight compensation is truly amazing and incredibly helpful for the images in shadows, highlight and backlight condition without the WDR function using frame memory.

Key features

  • Automatically generate the tone curves depending on a scene
  • Preserve the local contrast, detail and true color
  • Wide dynamic range function without frame memories
  • Backlight , shadow and highlight image compensation

What’s Included?

  • FPGA Level License version
    • FPGA level netlist for FPGA
    • Functional simulation support
    • Full functionality in with no time outs
  • RTL source Level License version
    • Original Verilog RTL source files
    • Functional simulation support
    • Full functionality in with no time outs

Specifications

Identity

Part Number
ASICFPGA WDR (Shadow and Highlight Compensation Core)
Vendor
ASICFPGA
Type
Silicon IP

Videos

HDR (high dynamic range) IP for FPGA/ASIC

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

ASICFPGA
HQ: Canada
Contact ASICFPGA
