ST2059-1&2 IP

Video transfer over IP, Supports PTP SMPTE ST 2059 is a standard for synchronization of video equipment over an IP network.

Contact Provider Request Datasheet

Overview

Video transfer over IP, Supports PTP

SMPTE ST 2059 is a standard for synchronization of video equipment over an IP network. The standard is based on IEEE1588. This IP generates a timing signal standardized in SMPTE ST 2059 using IEEE1588v2 Precision Time Protocol (PTP). The timing signal is utilized as “GenLock” signal which has been used in conventional A/V system.

Specifications

  • IPv4 Base
  • Supports both Master and Slave
  • Video/Audio AP output
  • 1pps output
  • TC output

Supported Devices

  • Cyclone V SX
  • Arria 10 SX

Key features

  • Supports IEEE 1588v2 Master/Slave mode
  • Flexible customization combining with FPGA HW
  • More tolerant for Network Jitter
  • Shorten Lock time

Block Diagram

ST2059-1&2 IP Package block diagram

Specifications

Identity

Part Number
ST2059-1&2 IP Package
Vendor
Macnica
Type
Silicon IP

Files

Product Sheet Download
