MIPI DSI-2 Verification IP

MIPI DSI-2 Verification IP provides an smart way to verify the MIPI DSI-2 bi-directional two-wire/three-wire bus. The SmartDV's MIPI DSI-2 Verification IP is fully compliant with version 2.0 MIPI Alliance specification for serial Interface and provides the following features.

MIPI DSI-2 Verification IP is supported natively in SystemVerilog, VMM, RVM, AVM, OVM, UVM, Verilog, SystemC, VERA, Specman E and non-standard verification env

MIPI DSI-2 Verification IP comes with optional Smart Visual Protocol Debugger (Smart ViPDebug), which is GUI based debugger to speed up debugging.

• Full MIPI DSI-2 Tx and Rx functionality.
• Supports 2.0 MIPI DSI-2 Specification.
• Support both DPHY and CPHY
• Supports MIPI DBI specification
• Supports MIPI DCS specification
• Supports all types of D-PHY short packets
• Supports all types of D-PHY long packets
• Supports all types of C-PHY short packets
• Supports all types of C-PHY long packets
• Supports all lane configuration
• Supports 8 lane configuration of DPHY layer
• Supports 4 lane configuration of CPHY layer
• Supports multiple packets per transmission
• Supports differential and single ended mode of operation
• Supports PPI interface
• Supports all BTA commands
• Supports Link Distribution Function
• Supports skew calibration
• Supports data scrambling
• Supports below data rates in DPHY layer
• 80 to 1500 Mbps per lane without deskew calibration
• Upto 2500Mbps per lane with deskew calibration
• Upto 12000Mbps per lane with equalization
• Supports below data rates in CPHY layer
• 17.1 Gbps for 3 lanes
• 5.7 Gbps for 1 lane
• Supports Display Stream Compression (DSC)
• Various kind of Tx and Rx errors generation and detection
• SoT error
• Sync error
• Word count error
• Sync length error
• Checksum error
• ECC error
• Supports detection of all timeouts and injection of various timeout errors
• Supports both high speed and low power packet transmission and reception
• Supports fine grain control of timing parameters
• Status counters for various events in bus.
• Operates as a Tx,Rx, or both.
• Monitor,Detects and notifies the testbench of all protocol and timing errors.
• Callbacks in node transmitter, receiver and monitor for user processing of data.
• MIPI DSI-2 Verification IP comes with complete test suite to test every feature of MIPI DSI-2 specification.
• Functional coverage for complete MIPI DSI-2 features

• Faster testbench development and more complete verification of MIPI DSI-2 designs.
• Easy to use command interface simplifies testbench control and configuration of Tx,Rx and monitor
• Simplifies results analysis.
• Runs in every major simulation environment.

• Complete regression suite containing all the MIPI DSI-2 testcases.
• Examples showing how to connect various components, and usage of Tx,Rx and Monitor.
• Detailed documentation of all class, task and function's used in verification env.
• Documentation also contains User's Guide and Release notes.
