Vendor: Shikino High-Tech CO.,LTD Category: Video Processing

Lossless JPEG Codec Full HD(YUV422) 24fps@100MHz. (1Sample/clk)

KJN-1LSC conform to the Lossless JPEG format(ITU-T T.81 Annex H) and compress/decompress image data without data loss in comparis…

Contact Provider Request Datasheet

Overview

KJN-1LSC conform to the Lossless JPEG format(ITU-T T.81 Annex H) and compress/decompress image data without data loss in comparison to normal lossy JPEG.

Key features

  • Complies with JPEG Standard ITU-T T.8 the Annex H.
  • Image Data I/O Format:Block Interleaved Format.
  • Image Size:Any size that can be divided by MCU unit.
  • Operation mode like processing mode, image size, DRI value etc. are set in internal register via external CPU.
  • Huffman table:Written from external during compression, and downloaded from compressed data during decompression.

Block Diagram

KJN-1LSC block diagram

Applications

  • Medical equipment,
  • highly advanced medical equipment,
  • broadcast equipment,
  • machine vision,
  • aerospace-related equipment and consumer devices (DSC,
  • DSC-SLR, smartphones, tablets, etc.)

What’s Included?

  • RTL:Verilog-HDL
  • C-Model
  • Specification Document
  • Simulation environment
  • Synthesis scripts

Specifications

Identity

Part Number
KJN-1LSC
Vendor
Shikino High-Tech CO.,LTD
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Contact Shikino High-Tech CO.,LTD
