Vendor: Shikino High-Tech CO.,LTD Category: Video Processing

JPEG Encoder Full HD(YUV422) 48fps@100MHz. (2Sample/clk)

The KJN-4ENC conform to the JPEG baseline format for compressing still images.

Contact Provider Request Datasheet

Overview

The KJN-4ENC conform to the JPEG baseline format for compressing still images.

Key features

  • The arithmetic accuracy satisfies the requirement of compliance testing of JPEG Part2 (ISO/IEC10918-2).
  • Image Data I/O Format:Block Interleaved Format.
  • Image Size:Any size that can be divided by MCU unit.
  • Operation mode like processing mode, image size, DRI value etc. are set in internal register via external CPU.
  • Quantization table / Huffman table:Fixed table is used for compression.
  • Marker:Automatically generated during compression. Processed marker: SOI,SOF0,SOS,DQT,DHT,DRI,RSTm,EOI
  • Internal SRAM:5Kbit -CPU bus:8bit -Image Data bus:16bit -Compressed Data bus:16bit -Quantization:4(RAM) -Huffman:DC 2,AC 2 (FIX) -Sub sampling:444,422, 420,411,Gray,CMYK

Block Diagram

KJN-4ENC block diagram

Applications

  • Digital still cameras
  • Video Phones
  • Image scanner
  • Printers
  • External board for PC
  • Surveillance systems
  • FAX
  • Image transfer devices
  • Mobile terminals
  • Smart phone
  • Tablet devices
  • Medical devices

What’s Included?

  • RTL:Verilog-HDL
  • C-Model
  • Specification Document
  • Simulation environment
  • Synthesis scripts

Specifications

Identity

Part Number
KJN-4ENC
Vendor
Shikino High-Tech CO.,LTD
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Shikino High-Tech CO.,LTD
HQ: Japan
Shikino High-Tech has created new value in the field of electronics, rooted in the Shikino spirit of nothing ventured, nothing gained. We continue to make progress with our exemplary design and development capabilities in those areas of technology which are our pride, including our module development centered around camera systems and image processing modules, design & development in the image processing sector based around our own JPEG IP technology, and the design and development of semi-conductor testing equipment such as LSI test development which contributes to the prompt startup of production lines and burn-in devices which guarantee total burn-in.
Contact Shikino High-Tech CO.,LTD
