Vendor: Techno Mathematical Co., Ltd. Category: Video Processing

JPEG Encoder 4-pixel/clock

Baseline JPEG hardware IP compliant to the ISO/IEC 10918-1 standard as a very compact and high-speed compression IP

JPEG Encoder View all specifications

Overview

Since its standardization of ISO/IEC 10918-1 in 1994, JPEG has been continued to be used as a still image storage format.

TMC has developed and commercialized a baseline JPEG hardware IP compliant to the ISO/IEC 10918-1 standard as a very compact and high-speed compression IP.

Specification

Compression Format JPEG (ISO/IEC 10918-1)
Throughput 4 pixels/clock @ YCbCr 4:2:2
Image Size 65k x 65k pixels (max.)
Image Format YCbCr 4:4:4/4:2:2/4:2:0/4:0:0
Bit Depth 8 bits
Interface Specification AXI3

This IP supports both color spaces of YCbCr and YUV.

Key features

  • By optimizing the encoding algorithm, TMC has achieved miniaturization and high speed.
  • Compared to the 1 pixel/clock version, it achieves 4 times higher performance with about twice the circuit size.
  • Due to its compact design, it can be implemented in inexpensive FPGAs to reduce the costs. (Example: Cyclone IV series, Artix7 series)
  • Simple interface makes it easy to integrate and shortens the design time.

Block Diagram

Click to open fullscreen

Specifications

Identity

Part Number
TM20135
Vendor
Techno Mathematical Co., Ltd.
Type
Silicon IP

Compute

Codec Standard
JPEG
Codec Mode
Encoder

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider
