Vendor: Silicon Creations Category: Multi-Protocol PHY

Multiprotocol SerDes PMA

Our SerDes architecture is in production in processes ranging from 12nm to 180nm and at rates from 100Mbps to 32.75Gbps and prove…

Contact Provider Request Datasheet
TSMC 40nm LP View all specifications

Overview

Our SerDes architecture is in production in processes ranging from 12nm to 180nm and at rates from 100Mbps to 32.75Gbps and proven in 6nm. We offer targeted PHYs including JESD204, XAUI, CPRI, SGMII, CPRI, OIF-CEI, V-by-One HS, Infiniband, PCIe1/2/3/4/5 and Serial RapidIO, and a Multiprotocol PMAs covering over 30 protocols from below 250Mbps to 32.75Gbps as well as SerDes designed for custom requirements. We partner with leading controller vendors to provide a complete solution, and can provide a complete PCIe PHY including PIPE PCS.

Key features

  • Supports over 30 protocols including CEI 6G & 11G SR, MR, LR, Ethernet 10GBASE-X/S/K/R, PCIe Gen1/2/3/4, V-by-One HS/US, CPRI, PON, OTN/OTU, 3GSDI, JESD204A/B/C, SATA1-3, XAUI, SGMII
  • Programmable (De)Serialization width: 8, 10, 16, 20, 32, or 40 bit
  • Tx ring PLL includes fractional multiplication, spread spectrum and Jitter Cleaner function for Sync-E and OTU
  • Core-voltage line driver with programmable pre-and post-emphasis
  • Out-of-band, electrical idle signaling capability for SAS, SATA, and PCIe
  • Ultra-low-Latency optimized PMAs with in-PMA latency below 13UI (<1.3ns at 10.3Gbps): See this overview.
  • Burst mode CDR with tCDR < 150UI
  • Programmable CTLE and adaptive 5-Tap Decision Feedback Equalizer for poor channels
  • Non-destructive eye monitor to measure eye opening at data slicer on chip

Block Diagram

SerDes block diagram

Applications

  • Programmable devices needing to support over 30 different protocols
  • AFE -- FPGA interfaces
  • 10G-KR Ethernet
  • SATA/SAS interfaces
  • UHD-TV (4k TV) displays
  • MFPs
  • Scanners
  • Semi-custom chip-chip interfaces
  • Backplanes

What’s Included?

  • GDSII
  • CDL Netlist (MG Calibre Compatible)
  • Functional Verilog Model
  • Liberty timing models (.lib)
  • LEF
  • Application Note with integration and production test guidelines
  • Signal Integrity simulations using customer package models

Silicon Options

Foundry Node Process Maturity
TSMC 40nm LP —

Specifications

Identity

Part Number
SerDes
Vendor
Silicon Creations
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Contact Silicon Creations
