UART CONTROLLER IIP

UART CONTROLLER interface provides full support for the two-wire UART CONTROLLER synchronous serial interface, compatible with UART specification. Through its UART CONTROLLER compatibility, it provides a simple interface to a wide range of low-cost devices. UART CONTROLLER IIP is proven in FPGA environment.The host interface of the UART CONTROLLER can be simple interface or can be AMBA APB, AMBA AHB, AMBA AHB-Lite, AMBA AXI, AMBA AXI-Lite, VCI, OCP, Avalon, PLB, Tilelink, Wishbone or Custom protocol.

UART CONTROLLER IIP is supported natively in Verilog and VHDL

• Implemented in Unencrypted Verilog, VHDL and SystemC
• Compliant with Standard UART 16550 Specification
• Full UART Functionality
• Transmit and receive commands allow the user to transmit and receive UART data
• Supports Character Mode, FIFO Mode and Extended FIFO Mode
• Supports 6, 7 and 8 data bits on serial inputs and output with 1,1.5 or 2 stop bits
• Parity, Framing and Overflow error detection
• Programmable Baud rate from 110 bps to 115.2 kbps
• Support additional functionality of IRDA, RS232, RS422, RS485 and GPIO
• Full duplex operation
• Fully configurable serial interface
• Supports character width from 1 bit to 32 bits
• Configurable receive FIFO depth
• Programmable Word length, Stop bits and Parity
• Automatic Data Formatting and status generation
• Interrupt Controller
• Modem Control interface with CTS,RTS,DSR,DTR,RI and DCD signals
• Provides bidirectional IRDA 1.4 Interface
• Programmable hardware flow control
• GPIO are supported using read and write commands
• Line break detection and generation
• This core achieves ASIL B and can be made to achieve ASIL D as per ISO26262

• Single Site license option is provided to companies designing in a single site.
• Multi Sites license option is provided to companies designing in multiple sites.
• Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
• Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.

• The UART Controller interface is available in Source and netlist products.
• The Source product is delivered in plain text verilog or VHDL or SystemC source code
• Integration testbench and tests
• Scripts for simulation and synthesis with support for common EDA tools
• Documentation contains User's Guide and Release notes.
• ISO26262 Safety Manual (SAM) Document
• ISO26262 Failure Modes, Effects and Diagnostics Analysis (FMEDA) Document
