Vendor: M31 Technology Corp. Category: ADC

SAR-ADC Temperature Sensor, TSMC 12FFC, N/S orientation

The M31 SAR ADC provides a rich portfolio with a resolution from 10 to 12-bit, maximum speed up to 2.5MSPS, and supports input ty…

TSMC 12nm FFC View all specifications

Overview

The M31 SAR ADC provides a rich portfolio with a resolution from 10 to 12-bit, maximum speed up to 2.5MSPS, and supports input types of single-ended or differential that give users great flexibility in their ASIC/SoC integration.

With patented innovative circuit techniques, the ADC can perform conversion as fast as the clock rate that is not commonly seen in the conventional SAR ADCs which often require a clock rate (Bit+N) X faster than the conversion rate. This feature eases the design complexity of system clock arrangement (and also the PLL/OSC) and saves power because of a reduced clock rate used by the ADC.

The ADC is intentionally designed to consume as small as possible current from the supply by combining several circuit techniques such that the ADC features an ultra-low-power (ULP) consumption. The ADC best suits the applications demanding extremely low power consumption like battery-powered products and Internet-of-Things (IoT).

Key features

  • Capable of sensing voltage or current within one smart sensor
  • Easy to drive with inherent filtering and programmable gain adjustment
  • Ultra low power & compact area

Block Diagram

SAR-ADC Temperature Sensor, TSMC 12FFC, N/S orientation block diagram

Silicon Options

Foundry Node Process Maturity
TSMC 12nm FFC —

Specifications

Identity

Part Number
SAR-ADC Temperature Sensor, TSMC 12FFC, N/S orientation
Vendor
M31 Technology Corp.
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
