The M31 SAR ADC provides a rich portfolio with a resolution from 10 to 12-bit, maximum speed up to 2.5MSPS, and supports input types of single-ended or differential that give users great flexibility in their ASIC/SoC integration.
With patented innovative circuit techniques, the ADC can perform conversion as fast as the clock rate that is not commonly seen in the conventional SAR ADCs which often require a clock rate (Bit+N) X faster than the conversion rate. This feature eases the design complexity of system clock arrangement (and also the PLL/OSC) and saves power because of a reduced clock rate used by the ADC.
The ADC is intentionally designed to consume as small as possible current from the supply by combining several circuit techniques such that the ADC features an ultra-low-power (ULP) consumption. The ADC best suits the applications demanding extremely low power consumption like battery-powered products and Internet-of-Things (IoT).
| Foundry | Node | Process | Maturity |
|---|---|---|---|
| TSMC | 22nm | ULL | — |
Note: some files may require an NDA depending on provider policy.
SAR-ADC, 12-bit, 1~2.5Msps, 8-input, TSMC 22ULL 2.5V, N/S orientation is a ADC IP core from M31 Technology Corp. listed on Semi IP Hub. It is listed with support for tsmc.
Engineers should review the overview, key features, supported foundries and nodes, maturity, deliverables, and provider information before shortlisting this ADC IP.
Yes. Buyers can compare this product with similar semiconductor IP cores or IP families based on category, provider, process options, and structured technical specifications.
