Vendor: Corepilot Category: PCI Express

PCIe Controller

High Performance, Small Area, Low Power | Flexible Controller Configuration Solution

Controller View all specifications

Overview

Corepilot provides high-performance, small-area, low-power, highly compatible, and flexibly configurable PCIe EP Gen5 controller IP, ASIC and FPGA solutions. It also offers customized design services for various PCIe EP applications.

The primary application scenarios include high-performance computing, artificial intelligence, storage, video and image processors, and automotive electronics.

Through efficient integration, it can significantly shorten customers’ project cycles.

Key features

  • Supports PCIe Gen1/2/3/4/5 speeds (2.5G/5G/8G/16G/32G bps), with maximum speed configurable as Gen3–Gen5
  • Supports x1, x2, x4, x8, and x16 lanes
  • Supports PIPE v5.2 protocol, including original PIPE mode and SerDes interface mode
  • 16-bit, 32-bit, and 64-bit data bus widths supported per lane on the PIPE interface
  • Supports AXI3/AXI4 and custom user interfaces
  • Supports automatic link polarity detection and inversion
  • Supports 256-bit, 512-bit, and 1024-bit internal data path widths
  • Atomic Operations
  • L1 low-power state
  • Data Link Control Packet Prefix
  • Single-Root I/O Virtualization (SR-IOV) supporting up to 4096 Virtual Functions (VFs)
  • Alternative Routing-ID Interpretation (ARI)
  • Address Translation Services (ATS)
  • TLP Processing Hints (TPH)
  • Process Address Space ID (PASID)
  • Active State Power Management (ASPM)
  • Advanced Error Reporting (AER)
  • End-to-End Cyclic Redundancy Check (ECRC)
  • Precision Time Measurement (PTM)
  • Access Control Services (ACS)
  • Lightweight Notification (LN)
  • Configurable RX and TX/replay buffer sizes
  • Configurable completion timeout
  • Configurable Maximum Payload Size
  • Supports Configuration Space Backdoor Access

Block Diagram

Click to open fullscreen

Applications

  • High Performance Computing
  • Storage Devices
  • Artificial Intelligence
  • Image Processing

Specifications

Identity

Part Number
PCIe Controller
Vendor
Corepilot
Type
Silicon IP
Controller / PHY
Controller

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
