Vendor: M31 Technology Corp. Category: MIPI PHY

MIPI DPHY_RX v1.2, 2C4D, TSMC 16FFC, E/W orientation (ASIL-B)

The D-PHY is a popular MIPI physical layer developed for mobile applications because it is a flexible, high-speed, low-power and …

MIPI D-PHY TSMC 16nm FFC View all specifications

Overview

The D-PHY is a popular MIPI physical layer developed for mobile applications because it is a flexible, high-speed, low-power and low-cost solution. As a MIPI Alliance contributor and leading Interface IP provider, M31 provides silicon-proven D-PHY in various process nodes. The D-PHY IP follows MIPI D-PHY v1.2/v1.1 spec and supports a wide range of high-speed (HS) and low-power (LP) data transfers. It is compliant to the PPI interface which allows seamless integration with upside controllers for Camera Serial Interface (CSI-2) and Display Serial Interface (DSI) protocols. Car manufacturers are also adopting MIPI specifications because the solutions are mature, relatively simple to use. M31 provides certified and compact PHY to support automotive applications.

Key features

  • Compliant with MIPI D-PHY specification up to v1.2/v1.1 (by different process nodes)
  • Supports MIPI DSI and CSI-2 protocols
  • Supports HS data rates up to 2.5Gbps (v1.2, per lane) . 1.5Gbps(v1.1, per lane)
  • Supports LS data rate of 10Mbps and Ultra-low power modes
  • Supports 1 clock lane & up to 4 data lanes
  • Supports extra RX mode with 2 sets of 1 clock lane & up to 2 data lanes
  • Provides swap function for clock and data lane to ease PCB design
  • Provides a stand-alone BIST module for at-speed mass production testing
  • Certified with ASIL-B of ISO-26262

Block Diagram

MIPI DPHY_RX v1.2, 2C4D, TSMC 16FFC, E/W orientation (ASIL-B) block diagram

Silicon Options

Foundry Node Process Maturity
TSMC 16nm FFC —

Specifications

Identity

Part Number
MIPI DPHY_RX v1.2, 2C4D, TSMC 16FFC, E/W orientation (ASIL-B)
Vendor
M31 Technology Corp.
Type
Silicon IP

Standards & Interfaces

MIPI PHY
MIPI D-PHY

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
