Vendor: Lattice Semiconductor Corp. Category: LPDDR

LPDDR3 SDRAM Controller

A Lattice FPGA based LPDDR3 solution – The Lattice Low Power Double Data Rate (LPDDR3) Synchronous Dynamic Random Access Memory (…

Contact Provider Request Datasheet
Controller View all specifications

Overview

A Lattice FPGA based LPDDR3 solution – The Lattice Low Power Double Data Rate (LPDDR3) Synchronous Dynamic Random Access Memory (SDRAM) Controller is a general-purpose memory controller that interfaces with industry standard LPDDR3 memory devices and modules compliant with the JESD-209.3 specification.

Easily integrate LPDDR3 into your design – This IP core reduces the efforts required to integrate the LPDDR3 memory controller with the remainder of the customer design.

Features * Interfaces to Industry Standard LPDDR3 SDRAM components and modules compliant with the JESD-209.3 specification
* High-Performance LPDDR3 performance, up to 400 MHz/800 Mbps operation
* Supports automatic LPDDR3 SDRAM initialization and refresh
* Supports Deep Power Down Mode


The LPDDR3 SDRAM Controller is available as a Clarity Designer user configurable IP core, which allows the configuration of the IP and generation of a netlist and simulation file for use in designs. Please note that generating a bitstream may be prevented or the bitstream may have time logic present unless a license for the IP is purchased.

Key features

  • Interfaces to Industry Standard LPDDR3 SDRAM components and modules compliant with the JESD-209.3 specification
  • High-Performance LPDDR3 performance, up to 400 MHz/800 Mbps operation
  • Supports automatic LPDDR3 SDRAM initialization and refresh
  • Supports Deep Power Down Mode

Block Diagram

LPDDR3 block diagram

Specifications

Identity

Part Number
LPDDR3
Vendor
Lattice Semiconductor Corp.
Type
Silicon IP
Controller / PHY
Controller

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
