IPsec Engine

The IPsec Engine implements RFC4301 and other relevant RFCs, providing confidentiality, connectionless data integrity, data-origin authentication and replay protection on OSI layer 3.

The scalable architecture provides low-latency, line rate acceleration of packet encapsulation, encryption and replay protection. Its modular design not only gives the ability to choose between different cryptographic algorithms, but also provides fine-grained control on classification features, packet formats, and more. Integration with a wide range of performance or area-optimized cryptographic IP cores allows unrivalled trade-off possibilities between throughput, area and latency.

Implementation aspects

At its very core, the IPsec Engine is completely technology-agnostic and can be integrated in a wide range of FPGA and ASIC technologies. On FPGA, the engine can use vendor-specific optimizations to reach very high throughput goals.

• Can aggregate several 10, 40 or 100 GbE link
• UDP encapsulation
• Compliant with RFC 4106, 4301, 4303, 7634
• Byte lifetime counters
• Supports AES-GCM-128/256
• Generic interface to TCAM
• 32 to 1024 bits datapath
• Supports IPv4 and IPv6
• ESP encapsulation/decapsulation
• 5-tuple classification
• Bypass mode
• Data interface: AMBA 4 AXI-Stream
• ASIC and FPGA
• Control interface: AMBA 4 APB

• Scalable architecture
• Low-latency

• Cloud computing
• Data center
• Edge router
• Edge networking for IoT data aggregation

• Netlist or RTL
• Scripts for synthesis & STA
• Self-checking TestBench based on FIPS vectors
• Documentation
