I3C Slave

IQonIC Works I3C Slave Core provides a slave interface for the following protocols: - I2C standard mode (100kbps) - I2C fast mode…

Overview

IQonIC Works I3C Slave Core provides a slave interface for the following protocols:
- I2C standard mode (100kbps)
- I2C fast mode (Fm, 400kbps) and fast-mode plus (Fm+, 1Mbps)
- I2C high-speed mode (3.4Mbps)
- I3C single data rate (SDR, up to 12.5Mbps)

Key features

  • Protocol engine implements the following I3C CCC commands: ENEC, DISEC, ENTAS0, RSTDAA, SETDAA, SETMWL, SETMRL, GETMWL, GETMRL, GETPID, GETBCR, GETDCR, GETSTATUS, GETMXDS, XTIME
  • XTIME ST, DT, TPH, and TU subcommands for timing control of a synchronous system
  • Dynamic address assignment, plus I2C legacy addressing
  • In-band Interrupts with configurable payload size
  • I3C error checking and recovery
  • Slave interface signals for private messages and CCC command data

Block Diagram

comm_i3c_slave_core block diagram

Benefits

  • IQonIC Works I3C Slave Core implements I3C protocol sequencing and command processing. It provides a simple interface for a device to transfer data over I3C. Legacy I2C protocols are supported transparently.

Applications

  • The MIPI I3C interface is an evolutionary standard that improves upon the features of I²C, while maintaining backward compatibility and is intended for use as a single interface that can be used for any sensor.
  • This standard offers a flexible multi-drop interface between the host processor and peripheral sensors to support the growing usage of sensors in embedded systems. The main purpose of MIPI I3C is threefold:
    • to standardize sensor communication,
    • reduce the number of physical pins used in sensor system integration and
    • support low-power, high-speed and other critical features that are currently covered by I²C and SPI.

What’s Included?

  • The following list of deliverables are included:
    • Datasheet
    • Synthesizable SystemVerilog RTL
    • Module Test Suite
    • Integration Guide

Specifications

Identity

Part Number
comm_i3c_slave_core
Vendor
IQonIC Works
Type
Silicon IP

Files

Product Sheet Download
