FFT Compiler
Lattice's FFT Compiler offers forward and inverse Fast Fourier Transforms for point sizes from 64 to 16384.
Overview
Lattice's FFT Compiler offers forward and inverse Fast Fourier Transforms for point sizes from 64 to 16384. This IP core can be configured to perform forward FFT, inverse FFT (IFFT) or port selectable forward/inverse FFT. The FFT compiler offers two choices of implementation: high performance (Streaming I/O) and low resource (Burst I/O). In the high performance implementation, the FFT IP core can perform real-time computations with continuous data streaming in and out at clock rate. There can also be arbitrary gaps between data blocks allowing discontinuous data blocks. The low resource implementation can be used when it is required to use lesser slices (logic unit of Lattice FPGA devices) and EBR (Embedded Block RAM) resources or if the device is too small to accommodate the high performance version.
To account for the data growth in fine register length implementations, the FFT compiler allows one of three fixed scaling or dynamic scaling after each radix-2 stage of the FFT computation. The low resource version also supports block floating point arithmetic that provides increased dynamic range for intermediate computations. The FFT compiler also allows the number of FFT points to be varied dynamically through a port.
To account for the data growth in fine register length implementations, the FFT compiler allows one of three fixed scaling or dynamic scaling after each radix-2 stage of the FFT computation. The low resource version also supports block floating point arithmetic that provides increased dynamic range for intermediate computations. The FFT compiler also allows the number of FFT points to be varied dynamically through a port.
Key features
- Wide range of points sizes: 64, 128, 256, 512, 1024, 2048, 4096, 8192, and 16384
- Choice of high-performance (streaming I/O) and low resource (burst I/O) versions
- Run-time variable FFT point size
- Forward, inverse or port-configurable forward/inverse transform modes
- Choice of no scaling, fixed scaling (RS111/RS211) and dynamically variable stage-wise scaling
- Data precision of 8 to 24 bits
- Twiddle factor precision of 8 to 24 bits
- Natural order for input and choice of bit-reversed or natural order for output
- Support for arbitrary gaps between input data blocks in high-performance realization
- Block floating point scaling support in low resource configurations
Block Diagram
FIR-COMP block diagram
Specifications
Identity
Part Number
FIR-COMP
Vendor
Lattice Semiconductor Corp.
Type
Silicon IP
Files
Note: some files may require an NDA depending on provider policy.
Provider
HQ:
USA
