E-Series GPU IP

One architecture for graphics, compute and AI

Overview

E-Series GPU IP features a deeply integrated Matrix Accelerator and support for low-precision number formats, ensuring fast and flexible acceleration for cutting-edge gaming and AI workloads.

Imagination E-Series GPU IP unifies graphics, compute and AI on one processor, with one software stack.

Matrix acceleration units deep inside the GPU’s shading clusters deliver efficient acceleration for popular but compute-heavy edge workloads like computer vision, generative AI and neural rendering.

The cost of developing advanced chips is enormous. Every mm² of silicon has to deliver value throughout the project’s lifecycle.

A general-purpose, GPU-based accelerator that can render a user interface, support an overloaded NPU and be trusted to run new models as they appear adds considerable value to a modern, edge AI system.

The Architecture of an E-Series Core

Understand how one GPU IP can handle graphics, compute and AI tasks. The single-core EXD-64-2048 GPU shown on the left delivers 64GTexel/s, 2 TFLOPS FP32 and 32 TOPS INT8 @ 1GHz.

  • RISC-V Firmware Processor
    • The firmware processor is in charge of scheduling workloads across the GPU, communicating with third party accelerators and handling errors. It operates independently of the CPU delivering superior performance.
  • Unified Shading Cluster (USC)
    • The USC is the programmable compute engine at the heart of every Imagination GPU. Inside each USC, an ultra-wide 128-lane ALU delivers massive parallel processing throughput, enabling efficient execution of graphics shaders, neural networks and general-purpose compute workloads on the same architecture.
  • Matrix Accelerator
    • Matmul acceleration with support for high and low precision number formats (FP32, FP16, BF16, INT8, FP8, MXFP8, FP4, MXFP4) is embedded deeply within the Imagination GPU’s ALU’s, sharing the same register storage for maximum data efficiency and power consumption.
  • Multi-core Scaling
    • Customers can scale E-Series up to cloud levels of performance using Imagination’s  decentralised, chiplet-friendly multi-core technology.
    • A quad-core E-Series GPU running at 1.6GHz reaches nearly 200 TOPS INT8.

Block Diagram

Click to open fullscreen

Specifications

Identity

Part Number
E-Series GPU IP
Vendor
Imagination Technologies Group Ltd.
Type
Silicon IP

Videos

E-Series: Why are GPUs perfect for AI?
Dennis Laudick, VP of Segment and Marketing at Imagination discusses why Imagination GPUs are essential for AI. Imagination’s E-Series GPU IP shatters performance, memory, and power barriers for AI at the edge. Designed to handle the demands of next-gen AI across mobile, automotive, desktop, and consumer markets, E-Series enables flexible, future-proof edge system design without over-reliance on fixed-function accelerators.

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Variants in this family

Part Number Short Description
EXT-64-2048 GPU EXT-64-2048 GPU
EXD-8-256 GPU EXD-8-256 GPU
