DDR3 SDRAM Controller

Key Features

Supports industry standard Double Data Rate (DDR2 and DDR3) SDRAM.
Pipeline access allows continuous data bursting and hidden command execution.
Page hit detection supports fast column access and multiple open banks.
High speed implementation with standard DFI support for hard DDR PHY.
Optional built-in soft PHY for low cost implementation.
Extensive general pupose registers for PHY support and calibration.
Numerous optional features such as multiple access ports, AHB, AXI and generic user interface, ECC, and others.
User controlled read and write latency.
On-die termination (ODT) and Off-chip Driver impedance adjustment (OCD) suports.
Programmable SDRAM access timing parameters and configurations.
Automatic refresh generation with programmable refresh intervals.
Self-refresh mode to reduce system power consumption.
Differentiating Features
- Multiple access ports with advance arbitration scheme.
- Multiple standard bus interface support (e.g. AHB, AXI, PowerPC, Wishbone, SH4).
- Different clock domaisn for access ports and SDRAM operation.
- Optional soft PHY or hard PHY interface.
