Vendor: Chipus Microelectronics Category: Voltage Reference

Bandgap Voltage Reference Low TC (13ppm/ °C), PSRR-42 dB @ 100kHz

This macro-cell bandgap voltage reference generator core designed for SilTerra 0.18µm CL18GH5 CMOS technology.

LFoundry 150nm View all specifications

Overview

This macro-cell bandgap voltage reference generator core designed for SilTerra 0.18µm CL18GH5 CMOS technology.

The core is ideal as a general purpose reference voltage in applications where low TC is required with quick response dynamic.

The circuit generates an unbuffered 1.23V, temperature compensated bandgap voltage reference (13ppm/◦C).

Internal start-up circuit allows that the reference voltage is available as soon as the power supply ramps up, so that no enable/disable function is necessary to start-up the circuit.

The core is easily re-targeted to any other CMOS technology

Key features

  • Vref=1.2325V ±0.35% (without trimming)
  • Supply voltage: 5 V
  • Current consumption: 32µA
  • Automatic start-up as soon as power supply starts
  • Current reference: 400nA
  • Indicative area: 0.0151mm2

Block Diagram

CM1215ff block diagram

Applications

  • Battery powered equipment
  • Passive/active RFID tag ICs
  • Energy Haversting ICs
  • Hearing Aids

What’s Included?

  • Datasheet/Integration Guide
  • HDL Model
  • Flat GDSII database/LVS netlist
  • Customer Support

Silicon Options

Foundry Node Process Maturity
LFoundry 150nm 150nm 1500 nm —

Specifications

Identity

Part Number
CM1215ff
Vendor
Chipus Microelectronics
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
