40nm 1.8V Programmable Band-Gap Reference with 0.55V output

The TRV701TSM40LP IP is a 1.8V low-power low-noise programmable 0.55V Band-Gap Reference implemented in TSMC Low-Power 40nm CMOS …

TSMC 40nm G View all specifications

Overview

The TRV701TSM40LP IP is a 1.8V low-power low-noise programmable 0.55V Band-Gap Reference implemented in TSMC Low-Power 40nm CMOS process technology. Its low noise and high-precision makes it especially suitable for use in wireless communication and broadcast integrated circuit subsystems (LTE, WiFi, WiMAX, DAB, DAB+, FM, HDFM, DRM, etc).

Key features

Precise Programmable 0.55V reference output voltage
2% reference output variation across process, supply and temperature
Flat reference output characteristics across temperature
Five 10uA Band-Gap Current Outputs

Block Diagram

TRV701TSM40LP block diagram

Benefits

Low-power and low-noise programmable 0.55V Band-Gap Reference
Band-Gap current outputs for re-creating Band-Gap voltages at any point on a large SoC or ASIC.

Applications

Band-Gap Reference is suitable for embedding in ASIC and SoC subsystems for:
LTE, WiFi, WiMAX, DAB, DAB+, FM, HDFM, DRM, and many more applications.

What’s Included?

Behavioural Models
Timing Models
GDSII Layout Database
Netlist for LVS verification
Usage and Integration Guidelines
Databook

Silicon Options

Foundry	Node	Process	Maturity
TSMC	40nm	G	—

Specifications

Identity

Part Number

TRV701TSM40LP

Vendor

Tetrivis

Type

Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.
