Vendor: M31 Technology Corp. Category: Single-Protocol PHY

USB4 Gen3 x2-lane PHY, TSMC N5, 1.2V, N/S orientation, type-C

The USB4 Gen3x2 transceiver IP provides a range of USB4 Gen3x2 host and peripheral applications up to 40Gbps.

Contact Provider Request Datasheet
TSMC 3nm N3X View all specifications

Overview

The USB4 Gen3x2 transceiver IP provides a complete range of USB4 Gen3x2 host and peripheral applications up to 40Gbps. It is compliant with the PIPE5.0 and UTMI+ specifications. The USB4 IP integrates high-speed mixed-signal circuits to support USB4 Gen3/Gen2/Gen1, USB 3.2 Gen2/Gen1 traffic. And could be backward compatible with USB 2.0/eUSB2 circuits. (480Mbps high-speed, 12Mbps full-speed, and 1.5Mbps low-speed data rates)

Key features

  • Compliant to USB4 Gen3(20G) / Gen2(10G)
  • Support USB4 Gen3 PIPE SerDes (128b/132b) coding
  • Support USB4 Gen2 PIPE SerDes (64b/66b) coding
  • Support PIPE USB3.2 Gen2 (128b/132b) coding
  • Support PIPE USB3.2 Gen1 (8b/10b) coding
  • Extra Sideband/CC Channel to manage the link.
  • Support both host and device features with type-C connector

Block Diagram

USB4 Gen3 x2-lane PHY, TSMC N5, 1.2V, N/S orientation, type-C block diagram

Silicon Options

Foundry Node Process Maturity
TSMC 3nm N3X —

Specifications

Identity

Part Number
USB4 Gen3 x2-lane PHY, TSMC N5, 1.2V, N/S orientation, type-C
Vendor
M31 Technology Corp.

Provider

M31 Technology Corp.
HQ: Taiwan
About M31 Technology M31 Technology Corporation (6643-TW) is a professional silicon intellectual property (IP) provider. The company was founded in July 2011 with its headquarters in Hsinchu, Taiwan. M31’s strength is in R&D and customer service. With substantial experiences in IP development, IC design and electronic design automation fields, M31 focuses on providing high-speed interface IPs, memory compilers and standard cell library solutions. M31 has close collaboration with world-class semiconductor companies. It has been aggressively investing in developing and validating different silicon IPs. Most IPs are targeted at advanced process technologies in various foundries. M31 provides customers with differentiated IP solutions. These solutions help customers grasp market opportunities in short design cycles, low manufacturing costs, and high product competitiveness. M31’s vision is to be the most trustworthy IP company in the semiconductor industry. For more information, please visit https://www.m31tech.com
Contact M31 Technology Corp.
