Arctan Function
ATAN_X calculates the inverse tangent of a fraction.
Overview
ATAN_X calculates the inverse tangent of a fraction. It has a fully pipelined architecture and uses fixed-point mathematics throughout. Input values are accepted as 16-bit unsigned fractions in the range 0 to 1. Output values are 16-bit unsigned fractions in the range 0 to π/4. Both input and output values are in [16 16] format with 0 integer bits and 16 fraction bits. As an example the input value 0x4000 would signify the fraction 0.5.
Key features
- Synthesizable, technology independent VHDL Core
- Function y = atan(x)
- Input range 0 ≤ x ≤ 1
- Output range 0 ≤ y ≤ π/4
- Based on a quadratic polynomial with dynamic coefficients
- Input values as 16-bit unsigned fractions
- Output values as 16-bit unsigned fractions in radians
- Accurate to within 0.00004 radians
- High-speed 250MHz+ operation1
- Fully pipelined architecture
- 3 clock-cycle latency
Block Diagram
ATAN_X block diagram
Applications
- Fixed-point mathematics
- Phase measurements in digital communications
- Alternative to using a 64k x 16-bit LUT (128 kbytes)
