Vendor: VeriSilicon Microelectronics (Shanghai) Co., Ltd. Category: Video Processing

High-efficiency, AI-based super resolution IP

The AI-SR series IPs offer super resolution solutions for enhancing video quality and pixel resolution, primarily used for post-p…

Contact Provider Request Datasheet

Overview

The AI-SR series IPs offer super resolution solutions for enhancing video quality and pixel resolution, primarily used for post-processing or display applications. Currently consisting of AISR1000 and AISR2000 IPs, this series enables generation or transfer of low-resolution sources for bandwidth reduction and performance improvement, while ensuring high-quality, high-resolution displays at the edge.

In addition to high performance, low power consumption, and small silicon footprint, AI-SR series delivers robust pixel processing features, including detail recovery, crispy edges, and thinning lines with jaggy-free results, resembling the orginal high-resolution image. With these features, AI-SR series is well suited for a wide range of applications, including consumer electronics, gaming, data centers, surveillance, and healthcare.

The AI-SR series operates in streaming mode, making it easy to integrate into pixel processing pipelines. It come with a lightweight, easy-to-use software stack, and is compatible with Android, RTOS, and any distribution of Linux systems.

Key features

  • Performance
    • AISR1000: up to 4Kx2K@60fps
    • AISR2000: up to 4Kx2K@144fps
  • Interfaces
    • FLEXA PSI for data input and output
    • APB interface for configuration
  • Input and Output Formats
    • YUV444, 10-bit data for each component
  • Pixel Processing Features
    • High quality Super Resolution solution with support for any scaling ratio at [1x, 5x]
    • Recover more fine details and texture naturally
    • Crispy edge with jaggy removed
    • Clear, sharp and thinning like original resolution
    • Robustness to meet different sources with diverse quality
  • Software Support
    • OS support: Linux, Android, RTOS
    • Light weight software driver

Block Diagram

AI-SR IP block diagram

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Specifications

Identity

Part Number
AI-SR IP
Vendor
VeriSilicon Microelectronics (Shanghai) Co., Ltd.

Provider

VeriSilicon Microelectronics (Shanghai) Co., Ltd.
HQ: USA
VeriSilicon Microelectronics (Shanghai) Co., Ltd. (VeriSilicon, 688521.SH) is committed to providing customers with platform-based, all-round, one-stop custom silicon services and semiconductor IP licensing services leveraging its in-house semiconductor IP. Under the unique "Silicon Platform as a Service" (SiPaaS) business model, depending on the comprehensive IP portfolio, VeriSilicon can create silicon products from definition to test and package in a short period of time, and provides high performance and cost-efficient semiconductor alternative products for fabless, IDM, system vendors (OEM/ODM), large internet companies and cloud service provider, etc. VeriSilicon's business covers consumer electronics, automotive electronics, computer and peripheral, industry, data processing, Internet of Things (IoT) and other applications. VeriSilicon presents a variety of customized silicon solutions, including high-definition video, high-definition audio and voice, in-vehicle infotainment, video surveillance, IoT connectivity, smart wearable, high-end application processor, video transcoding acceleration and intelligent pixel processing, etc. In addition, VeriSilicon has six types of in-house processor IPs, namely GPU IP, NPU IP, VPU IP, DSP IP, ISP IP and Display Processor IP, as well as more than 1,400 analog and mixed signal IPs and RF IPs. Founded in 2001 and headquartered in Shanghai, China, VeriSilicon has 7 design and R&D centers in China and the United States, as well as 11 sales and customer service offices worldwide. VeriSilicon currently has more than 1,200 employees.
